      Fiberglass Cable

      Fiberglass Cable
      Fiberglass Cable
      Product Code : FGC08
      Brand Name : ELTEC
      Price And Quantity
      • Minimum Order Quantity
      • 100
      • Unit of Measure
      • Meter/Meters
      Product Specifications
      • Product Type
      • HIGH TEMPERATURE CABLES
      • Material
      • FIBER GLASS BRAIDED
      • Function
      • POWER
      • Voltage Surge
      • 600 V / 1100 V
      • Insulation Material
      • FIBER GLASS
      • Conductor Material
      • Bare Copper Conductor
      • Length
      • 100 / 200 / 500 Meter (m)
      • Size
      • 0.5 sq.mm to 125 sq.mm
      Product Description

      Fiber Glass Wires and Cables are high temperature cables, which has an outstanding and unique combination of electrical, thermal, mechanical & chemical properties. Cable conductors like annealed bare or tinned copper are closely braided with FIBER GLASS Yarn and impregnated with high temperature impregnation.

      They are normally recommended for continuous use from 130 to 180 °C with impregnation and up to 500°C without impregnation. FIBER GLASS WIRES are ideal for general application requiring moderate abrasion, moisture resistance & high temperature resistance. It has got superior thermal properties as it dissipates heat faster and high thermal endurance as it cannot be burned.

      APPLICATIONS

      • Hook up wires for high temperature panels
      • Wiring for Heaters, Ovens & Furnace
      • Transformer winding
      • Power Cables for Boiler & various High Temperature Processing Equipments
      • High Temperature Motors, Transformers & Rectifiers

      FEATURES

      • Continuous use up to 450 °C without impregnation
      • Good Thermal Properties as it dissipates heat faster
      • Flame Retardant
      • Superior Abrasion Resistance
      • High Die Electric strength and low die electric constant

      SPECIFICATIONS

      • Conductor - Annealed Bare Copper, Tin Plated Copper, Nickel Plated Copper, Copper – SS Mix conductor
      • Core Insulation - Braided Fiber Glass Yarn with High Temperature Impregnation
      • No. of Core - Single or Multi core
      • Construction - Parallel or Twisted
      • Outer Sheath - Braided Fiber Glass Yarn with High Temperature Impregnation
      • Outside Jacket - Outside SS Metal braid





      Trade Information
      • Sample Policy
      • Free samples are available
      • Packaging Details
      • COIL PACKED IN CARTON
      • Main Domestic Market
      • All India
      • Certifications
      • ISO 9001:2015 CE RoHS
