      Thermocouple Extension Cables

      Thermocouple Extension Cables
      Thermocouple Extension Cables
      Product Code : THR07
      Brand Name : Eltec
      Product Description

      THERMOCOUPLE COMPENSATING / EXTENSION CABLE:



      We manufacture wide range of THERMOCOUPLE EXTENSION / COMPENSATING CABLES used for carrying data signals generated by THERMOCOUPLE to the control panel. It may also be used to build the sensing point and can be used as a K TYPE THERMOCOUPLE SENSOR or used in manufacturing THERMOCOUPLE ASSEMBLIES or can used to connect to DATA LOGGERS via THERMOCOUPOLE CONNECTORS.

      Available Thermocouple Calibration in EXTENSION & COMPENSATING Grade are J, K, T, E, N, R, S, B etc.



      CONSTRUCTIONAL DETAILS:



      Conductor

      Solid or Multi stranded

      Core Insulation

      As per the table i.e. PTFE / FIBER GLASS / CERAMIC / SILICA YARN / KAPTON SILICON

      Core Laying

      Parallel or twisted

      No. of Pair

      1, 2 or more

      Screening

      Braided Copper wires / silver or tin plated copper wires / Alu. Mylar with drain wire

      Outer Sheath

      As per the table i.e. PTFE / FIBER GLASS / CERAMIC / SILICA YARN / KAPTON SILICON

      Braiding

      Fine annealed soft mirror finished SS WIRE

      Armoring

      GI Round Wire

      Color Coding

      As per IEC, ANSI, DIN etc. Refer Table



      CORE INSULATION

      SHEATH INSULATION

      MAX. TEMP.

      INSULATING MATERIAL CHARACTERISTICS

      PTFE  TAPPED

      PTFE

      250 °C

      Resistant to Abrasion, oil, moisture etc with high electrical properties.

      FIBER GLASS BRAIDED

      FIBER GLASS

      400 °C

      Good temperature resistant

      PVC

      PVC

      70 °C

      Versatile for normal application

      NEOPRENE RUBBRE

      NEOPRENE RUBBER


      Greater flexibility with god temp. resistant.

      SILICONE EXTRUDED

      SILICONE EXTRUDED

      200 °C

      Excellent flexibility with good temperature resistant.
